Product Description
1. The 2PC forged steel soft seal ball valve adopts two piece split structure. The valve body consists of left and right sections connected by threads. It has high structural strength and reliable sealing, suitable for high pressure working conditions.
2. Featuring split body construction, the valve is compact, lightweight and high strength, well suited for small bore high pressure pipelines.
3. The valve stem is of bottom mounted design, offering low operating torque for easy opening and closing.
4. Designed in compliance with ASME B16.34 and other standards, this valve covers pressure rating ANSI Class 800LB. It is widely applied as a shut off device in pipelines handling water, air, natural gas, oil products and other media to achieve medium cut off and isolation.
Features & Benefits
1. Forged Steel Construction: The valve body is machined from two steel forgings with no casting defects. It features high structural strength and excellent pressure resistance.
2. Superior Soft Seal: PTFE or RPTFE seats match with precision ball to provide bi directional zero leakage sealing.
3. Safe Stem Structure: Bottom mounted anti blowout stem design eliminates the risk of stem ejection.
4. Fire Safe and Anti Static Design: Equipped with fire safe and anti static structure, suitable for flammable and explosive media.
5. Accurate Handle Indication: Flat stem structure allows the handle position to accurately indicate valve open or closed status.
6. Locking Mechanism: Stops are set at fully open and fully closed positions to prevent misoperation.
7. Easy Operation: Precision fit between ball and stem creates low friction, resulting in low operating torque and smooth handle operation.
