Engineering Plastic Sampling Valve

Short Description:

  • Nominal Size: NPS 1/4"~NPS 1/2"
  • Pressure Class: ANSI Class 150Lb
  • Operating Temperature: -20℃~+140℃
  • Working Pressure: 0~10Bar
  • Applicable Media: Chemical corrosive fluid, high purity pharmaceutical liquid, electroplating acid-base medium, environmental sewage, crystalline medium
  • Design Standard: Designed according to engineering specifications, no dedicated product ISO standard
  • End Connection: Thread, True union
  • Actuation: Manual Precise Micro-sampling Regulation
  • Body Materia: UPVC, CPVC, PPH, PVDF
  • Seat Material: EPDM, FKM, PTFE
  • Test Standard: ISO 9393-1:2004
  • Product Detail

    Product Tags

    Product Description

    1. The engineering plastic sampling valve is professional equipment for corrosive medium sampling. The full plastic structure without metal contact completely avoids sampling pollution.

    2. Adopt high purity UPVC, CPVC, PPH and PVDF anti corrosion materials with acid and alkali resistance to adapt to harsh working conditions.

    3. Built in micro throttling valve core realizes accurate micro sampling without residue and mixing to ensure detection accuracy.

    4. Sealed anti volatilization structure ensures safe and environment friendly operation, suitable for high frequency and high cleanliness sampling.

    5. Widely used in chemical, pharmaceutical, electroplating and environmental protection industries to meet precision sampling demands of corrosive media.

    Features & Benefits

    1. Adjustable and accurate micro sampling without residue and cross contamination, suitable for precision detection scenarios.

    2. Full plastic high cleanliness anti corrosion structure adapts to high purity and toxic strong corrosive media.

    3. Sealed anti volatilization design avoids medium volatilization risk with safe and eco-friendly operation.

    4. Multiple material options with wide adaptability, reusable and greatly reduce operation and maintenance costs.

    5. Simple and accurate manual adjustment, suitable for high frequency regular sampling operation.
